核心原理：读取elf头，判断机器类型是否为x86过检测方法（以雷电模拟器4为例）：第一种方法（推荐使用这种方法）：修改系统/system/lib中所有so的机器类型，改为arm，但是这样改了之后，加载so会报 unexpectede_machine，解决办法就是去掉系统加载so过程中判断机器类型的代码段。打开android7.1源码中linker_phdr.cpp，在VerifyElfHearder函数开头加上return true; 这样linker链接的时候就不会去判断elf头，也就不会报错，然后编译linker，把编译出来的linker替换掉模拟器中的/system/bin/linker，再重启模拟器即可。以后直接打开游戏就能过检测了。
下载附件
2021-2-26 07:43 上传
以下是 scan_emulator_release 的lua代码：[Lua] 纯文本查看 复制代码
local function is_null(p) if p == 0 or p == nil then return true end return false end local function find_str(s1, s2) local n1,n2 = string.find(s1, s2, 1, true) if (n1 ~= nil and n2 ~= nil) then return true end return false end local function str_startswith(s1, s2) local n1, n2 = string.find(s1, s2, 1, true) if (n1 ~= nil and n2 ~= nil and n1 == 1) then return true end return false end local function str_endswith(s1, s2) local n1, n2 = string.find(s1, s2, 1, true) if (n1 ~= nil and n2 ~= nil and n2 == #s1) then return true end return false end local function open_file_exists(s_path) local is_valid_path = false if (str_startswith(s_path,"/system/") or str_startswith(s_path,"/data/") or str_startswith(s_path,"/lib/") or str_startswith(s_path,"/sbin/") or str_startswith(s_path,"/sys/")) and (str_endswith(s_path,".so")) then is_valid_path = true end if not is_valid_path then return false end local f = io.open(s_path, "r") if f then io.close(f) end return f ~= nil end local function bin2hex(s) s=string.gsub(s,"(.)",function (x) return string.format("%02X",string.byte(x)) end) return s end local function basename(str) local name = string.gsub(str, "(.*[\\/])(.*)", "%2") return name end local function check_elf_file_x86_emulator(file_path) local ret = 0 if not open_file_exists(file_path) then return ret end local f = io.open(file_path,'rb') if f then local sizes = f:seek("end") if sizes > 1024 then f:seek("set") local content = f:read(4) local hexstr = bin2hex(content) if hexstr == "7F454C46" then local is_32_64 = f:read(1) hexstr = bin2hex(is_32_64) if hexstr == "01" then f:seek("set",18) local cpu_type = f:read(2) hexstr = bin2hex(cpu_type) if hexstr == "0300" then ret = 1 end end end end f:close() end return ret end local function get_int_value(key, deft) local value = TssSDK.get_value_by_key(key) if not is_null(value) then local int_val = tonumber(value) if int_val then return int_val end end return deft end local g_mark_scan_flag = "llua_ser_20200421_scanned" local g_module_cnt = 0 local g_libc_files_cnt = 0 local g_has_x86_file = 0 local g_x86_file_name = "" local g_tp_ver = "" local g_libhoudini_file_name = "" local g_libhoudini_file_size = 0 local function save_scan_result() TssSDK.set_key_and_value("LEMC", ""..g_module_cnt) TssSDK.set_key_and_value("LEFC", ""..g_libc_files_cnt) TssSDK.set_key_and_value("LEHX", ""..g_has_x86_file) TssSDK.set_key_and_value("LEXN", g_x86_file_name) TssSDK.set_key_and_value("LETV", g_tp_ver) TssSDK.set_key_and_value("LENM", g_libhoudini_file_name) TssSDK.set_key_and_value("LESZ", ""..g_libhoudini_file_size) end local function load_scan_result() g_module_cnt = get_int_value("LEMC", 0) g_libc_files_cnt = get_int_value("LEFC", 0) g_has_x86_file = get_int_value("LEHX", 0) g_x86_file_name = TssSDK.get_value_by_key("LEXN") g_tp_ver = TssSDK.get_value_by_key("LETV") g_libhoudini_file_name = TssSDK.get_value_by_key("LENM") g_libhoudini_file_size = get_int_value("LESZ", 0) end local function get_tp_ver() local try_cnt = 0 local err_msg = "" local err_code = 0 local dev_path = "/dev/virtpipe-sec" while (try_cnt < 3) do try_cnt = try_cnt + 1 local ret, acode = TssSDK.access(dev_path) if (ret ~= 0) then err_msg = "unfound" err_code = acode else local session = TssSDK.OpenWBSession() if (is_null(session)) then err_msg = "open_failed" local file, err, ocode = io.open(dev_path, "r+") if (file) then file:close() end if (ocode ~= nil) then err_code = ocode else err_code = 0 end else local tp_ver = TssSDK.SendWBCmd(session, "func=WB_GetTPShellVersion") TssSDK.CloseWBSession(session) if (is_null(tp_ver) or type(tp_ver) ~= "string") then err_msg = "get_failed" err_code = 0 else return tp_ver.."-"..tostring(0) end end end TssSDK.sleep(1000) end return err_msg.."-"..tostring(err_code) end local function scan_emulator() local try_cnt = 5 local handle = TssSDK.open_tphm() while (try_cnt > 0 and is_null(handle)) do TssSDK.sleep(1000) handle = TssSDK.open_tphm() try_cnt = try_cnt - 1 end if is_null(handle) then return end local libc_name = "libc.so" local libc_files = {} local libhoudini_name = "houdini" while g_module_cnt < 10000 do local module_info = TssSDK.enum_tphm(handle) if is_null(module_info) then break end g_module_cnt = g_module_cnt + 1 local module_name = TssSDK.get_tphm_name(module_info) local module_size = TssSDK.get_tphm_size(module_info) if not is_null(module_name) and not is_null(module_size) then local file_name = basename(module_name) if find_str(file_name, libc_name) then if libc_files[module_name] == nil then g_libc_files_cnt = g_libc_files_cnt + 1 libc_files[module_name] = {} end elseif find_str(file_name, libhoudini_name) then if g_libhoudini_file_name == "" then g_libhoudini_file_size = module_size g_libhoudini_file_name = module_name end end if g_has_x86_file == 0 then g_has_x86_file = check_elf_file_x86_emulator(module_name) if g_has_x86_file == 1 then g_x86_file_name = module_name g_tp_ver = get_tp_ver() end end end end save_scan_result() TssSDK.close_tphm(handle) end local function get_report_cnt() local cnt = get_int_value("LERC", 0) cnt = cnt % 1000 + 1 TssSDK.set_key_and_value("LERC", ""..cnt) return cnt end local function report_emulator() local emu_name = TssSDK.QueryStr("emulator_name") local maybe_emu = 1 if (emu_name == "NotEmulator") then maybe_emu = 0 end local is_download = TssSDK.IsEnabled("simulate", 0) local report_cnt = get_report_cnt() local info = tostring(g_has_x86_file).."|"..tostring(g_libc_files_cnt).."|"..tostring(g_libhoudini_file_size).."|"..tostring(maybe_emu).."|"..tostring(report_cnt) TssSDK.set_key_and_value("li_emu", info) TssSDK.ReportQosByGame(8, 2020061700, g_has_x86_file, g_libc_files_cnt, g_libhoudini_file_size, g_module_cnt, maybe_emu, is_download, report_cnt, 2, emu_name..','..g_libhoudini_file_name, g_tp_ver..','..g_x86_file_name) end local function has_scanned() return (not is_null(TssSDK.get_value_by_key(g_mark_scan_flag))) end local function set_scanned() TssSDK.set_key_and_value(g_mark_scan_flag, "1") end local function do_exec() if TssSDK.get_platform() ~= 0 then return end if (has_scanned()) then load_scan_result() else scan_emulator() set_scanned() end report_emulator() end local function exec() local ver = TssSDK.get_sdk_version() if is_null(ver) then return end local target_ver = "3.7.13.548645" if ver < target_ver then return end do_exec() end exec()
